DESCRIPTION
FEATURES & BENEFITS
- Efficient Lighting: Half the power of halogen lamps for brighter illumination.
- Easy Installation: Fits 7"/PAR56 style sealed beam headlamps with H4 connector.
- DOT Approved: Ensures 100% street legality and safety compliance.
- Enhanced Driving: Improved visibility, reduced electrical strain.
- Vintage Style: Timeless design for safety and aesthetics.
WHAT’S INCLUDED
Housing: 1x Model 8700 Evo 2 Classic
WARRANTY INFORMATION
TECHNICAL SPECIFICATIONS
Output: 1,770lm (Raw / Low Beam), 3,200lm (Raw / High Beam)
Current: 2.0A (Low), 3.5A (High) @ 12V DC
Input Voltage: 9-32V DC
Material: Aluminum (Housing), Polycarbonate (Lens)
Dimensions: 6.95in H, 6.95in W, 3.93in D
Pinout: Black - Ground, White - High, Yellow - Low
COMPATIBILITY
557661: JW Speaker: 8700 Evo2 Classic (Each)
Replaces OE Part #: H6024
Drive anytime with confidence. The J.W. Speaker 8700 Evo 2 Classic draws less than half the power of halogen lamps while providing a brighter, enhanced driving experience. Reduce the demand on your classic ride's electrical system and your eyes at night.
Car aficionados know a sleek design is key. J.W. Speaker designed the 8700 EVO 2 Classic headlights to be a simple install. Easy Retrofit: fits numerous classic cars that use a 7"/PAR56 style sealed beam headlamp and H4 connector.
Drive with style and safety. The 8700 EVO 2 Classic is DOT approved and tested to be 100% street legal - unlike replacement LED bulbs. Make the Model 8700 EVO 2 Classic your primary choice for safety and vintage aesthetics.
